P r o d u c t S p e c i f i c at i o n s :
M o d e l s : I Q 3 3 /4 3 / I Q H 1 3 / I Q H 3 3 / I Q H 4 3
Woodbox combustion technology
Outside air ready
Heat-reactive white cast iron interior
Cast iron door
Clean glass system
Ashpan / Fan included
Three and four-sided frame options
Optional remote control available
T e c h n i c a l D ata :
S ta n d a r d F e at u r e s :
36
IQ33
IQ43
IQH13
IQH33
IQH43
Min.-max. heat output
2 - 12 kW
2,5 - 14 kW
2 - 8 kW
3 - 14 kW
4 - 16 kW
Heat output to EN13240
9 kW
10,5 kW
6,5 kW
9 kW
12 kW
Heating capacity
360 m³
420 m³
260 m³
360 m³
480 m³
Efficiency rating
80%
80%
75%
81%
77%
CO Emissions
0,135%
0,06%
0,1%
0,08%
0,08%
Flue diameter
150 mm
180 mm
125 mm
180 mm
180 mm
Maximum log length
400mm
550mm 550mmvert./330mm horiz.
550mmvert. /400mm horiz.l
550mmvert./500mm horiz.
Weight
135 kg
182 kg
146 kg
178 kg
197 kg
Certification
EN 13229
EN 13229
EN 13229
EN 13240
EN 13229
L [mm]
584
692
442
584
692
H1 [mm]
695
717
908
961
897
H2 [mm]
643
668
868
909
845
h [mm]
644
666
871
912
848
I [mm]
583
691
442
583
691
P [mm]
450
498
444
450
498
b [mm]
371
421
379
371
421
a [mm]
249
280
232
249
280
D [mm]
150
180
125
150
180
d [mm]
120
120
100
120
120
D I M E N S I O N S AV E C C A D R E S
IQ33
IQ43
IQH13
IQH33
IQH43
LC / HC LC / HC LC / HC LC / HC LC / HC
Cadre 3 côtés largeur 25 mm
618 / 661
726 / 683 618 / 927 618 / 927 726 / 863
Cadre 4 côtés largeur 25 mm
618 / 678 726 / 700 618 / 944 618 / 944 726 / 880
Cadre 3 côtés largeur 50 mm
668/686 776 / 708 668 / 952 668 / 952 776 / 888
Cadre 4 côtés largeur 50 mm
668 / 728 776 / 750 668 / 994 668 / 994 776 / 930
