Tertio
10H
FEUCONTINU
T54
T64 - 74
T64-640V-
670V-690V
33
cm
STANDARD
BÛCHES
Orféo
STANDARD
BÛCHES
50
cm
2
2+1
1,75 m
Tertio 74
102
Technical characteristics: see page 115
Use as a built-in fire in a new fireplace
or as a insert-firebox (to add to an
existing fireplace)
Double-envelope stainless steel
smoke baffle.
Connection nozzle removable
from the inside; easy to install;
easy to maintain
"Clean glass" system
Strong
points
Adaptable to
the ORFEO
range of deco-
rative fronts
See page 10
TERTIO 54, 64 and 74
are also available in:
54 D, 64 D AND 74 D
versions with automatic door spring.
Tertio turbo
T54
"Flamme Verte" quality charter
French standard
Clean glass system
For 50 cm logs*
For 33 cm logs*
Triple envelope heating body (2 + 1):
airtight combustion chamber + interior lining
+ third envelope for greater safety
Heating body with cast iron lining
TERTIO AND TERTIO TURBO
T74-740V-
760V-790V
Optional support foot available
Ashpan accessible while
the fire is in use
Air distributor included
Optional turbines
Surface heated (table p. 113)
Surface heated (table p. 113)
Surface heated (table p. 113)
Continuous fire,
the embers last over 10 hours
TERTIO 74
Width 76 cm
Output 70 %
Nominal output 12 kW
All glass door
10 hours continuous burning
Reversible hearth plate
Options :
• Warm air nozzles
Ø
125 mm or 150 mm
• KT76 turbine kit
• PS76 support foot
• Beam protection kit
• T76 Orféo decorative front
• CF 76 trim frame
TERTIO 54
Width 55 cm
Output 70 %
Nominal output 7 kW
All glass door
2 nozzles
Ø
125 mm included
Options :
• KT55 turbine kit
• PS55 support foot
• Beam protection kit
• CF 55 trim frame.
TERTIO 64
Width 67 cm
Output 77 %
Nominal output 9 kW
All glass door
10 hours continuous burning
Reversible hearth plate
Options :
• Warm air nozzles
Ø
125 mm or 150 mm
• KT67 turbine kit
• PS67 support foot
• Beam protection kit
• T67 Orféo decorative front
• CF 67 trim frame
MODEL
TERTIO
DOOR OPENING
SIDE
REF.
DIMENSIONS W X H X D
VERSIONS
54
111877
55
X
44
X
39 cm
64
111879
67
X
50
X
46 cm
74
111881
76
X
59
X
48 cm
54 D
111883
55
X
44
X
39 cm
64 D
111884
67
X
50
X
46 cm
74 D
111885
76
X
59
X
48 cm
All glass door
* Indication of the standard size of logs on general sale.
