Tertio
STANDARD
BÛCHES
50
cm
2
2+1
99
Technical characteristics: see page 115
Strong
points
Side view 1 side
TERTIO 67 VL1
Width 67 cm
Output 77 %
Nominal output 9 kW
Window on right
(can be reversed to left)
Options :
• Warm air nozzles
Ø
125 or 150 mm
• KT67 turbine kit
• PS67 support foot
• Beam protection kit
TERTIO 76 VL1
Width 76 cm
Output 70 %
Nominal output 11 kW
Window on right
(can be reversed to left)
Options :
• Warm air nozzles
Ø
125 or 150 mm
• KT76 turbine kit
• PS76 support foot
• Beam protection kit
Side view, 1 side
Use as a firebox in a new fireplace
or as insert (to add to an existing
fireplace)
Double-envelope stainless steel
smoke baffle.
Considerably increases the output
and efficiency of the fire
Nozzle removable from
the inside; easy to install
Side window supplied
on the right side, can be reversed
to the left on installation
"Clean glass" system
MODEL
TERTIO
DOOR OPENING
SIDE
REF.
VERSIONS
67 VL1
111204
76 VL1
111207
67 VL1 D
111211
76 VL1 D
111214
The TERTIO 67 VL1 and 76 VL1
are also available in:
67 VL1 D AND 76 VL1 D
versions with automatic door spring.
* Indication of the standard size of logs on general sale.
"Flamme Verte" quality charter
French standard
Clean glass system
For 50 cm logs*
Triple envelope heating body (2 + 1):
airtight combustion chamber + interior lining
+ third envelope for greater safety
Heating body with cast iron lining
Optional support foot available
Ashpan accessible while
the fire is in use
Air distributor included
Optional turbines
Surface heated (table p. 113)
Surface heated (table p. 113)
Smoke collector with Inoxis HR smoke
baffle: helps concentrate the heat and
amplifies the clean glass system
67 VL1
76 VL1
