Astra
1,75 m
STANDARD
BÛCHES
50
cm
ASTRA 2
10H
FEUCONTINU
Astra 2
92
Technical characteristics: see page 114
Economical and efficient
Output 78 %
Nominal output 10 kW (Astra 2)
Cast iron interior; wave hearth plate»
Cast iron plates removable from the inside if
replacement needed: no need to dismantle the fireplace
Cast iron door; side opening
Stainless steel smoke baffle
Flue valve
Ashpan accessible during operation 5.2 l.
"Clean glass" system»
Options :
• Warm air distributor DA101
• CP101 casing
• Extra warm air nozzles
(if DA101)
ø
125 mm
• PS67 support foot
Strong
points
Astra 2 is also
available in:
ASTRA 2 D
version with automatic
door spring.
MODEL
ASTRA 2 / 2 D
DOOR OPENING
SIDE
REF.
111893
/
111894
"Flamme Verte" quality charter
French standard
Clean glass system
For 50 cm logs*
Entirely cast iron heating body
Flue valve:
reduces wood consumption
Surface heated (table p. 113)
Optional support foot available
Ashpan accessible
while the fire is in use
Continuous fire,
the embers last over 10 hours
Optional air distributor
* Indication of the standard size of logs on general sale.
