Classiques
1,75 m
150 C / 150 CD
94
Technical characteristics: see page 114
Outstanding performance
Continuous fire, 10 hours
(except 162C-168C)
Cast iron firebox
Cast iron plates removable from the
inside of the firebox: if replacement
is needed, no need to dismantle the
fireplace!
Automatic flue valve
Large ashpan : 7 l.
Independent ashpan door to remove
the ash while the fire is in use
"Clean glass" system»
Strong
points
AUTOMATIC OPENING
FLUE VALVE
When the door is opened, the flue valves opens
automatically. This prevents a maximum of
smoke billowing out into the room.
(*) Side opening for easy cleaning of the glass.
760
390
622
750
40
Ø200
518
1043
1023
40
20
746
148 C
150 C / 150 CD
150 C
Output 73 %
Nominal output 13 kW, 9 kW (150 CD)
Side-opening door
Support foot and casing included
Options :
• CDA 150 C cover
• KTE 152 biturbo kit
• 2 extra hot air nozzles
(if CDA 150 C)
Ø
150 mm
• Grill kit
148 C
Output 73 %
Nominal output 13 kW
Side-opening door
Optional:
• Grill kit
MODEL
CLASSIQUES
DOOR OPENING
SIDE
REF.
LIFT-UP*
REF.
VERSIONS
148 C 111401
162 C
111412
150 C 111400
152 C 111410
168 C
111411
150 CD 111408
152 CD 111409
