65
perfect
cool
PC.ZX105E
FOG ECO 05
PC.ZX101E
FOG ECO 1
PC.ZX103E
FOG ECO 3
a
b
c
PC.KW202 PC.KW402
1
1
2
4
2
4
25
50
20
40
4
8
1
3
8
16
Code
Model
* No.
nozzles
Pressure Flow rate
Power absorbed
Dimensions
W x L x H
Weight
11
60 bar
850 psi
0,5 l/min
0.13 USGpm
200 W (1x230 V-50 Hz)
41 x 26 x 26 cm
16.2” x 10.3” x 10.3”
gr.
15000
529.1
22
60 bar
850 psi
0,9 l/min
0.24 USGpm
200 W (1x230 V-50 Hz)
41 x 26 x 26 cm
16.2” x 10.3” x 10.3”
gr.
15000
529.1
70
60 bar
850 psi
3 l/min
0.80 USGpm
750 W (1x230 V-50 Hz)
55 x 35 x 32 cm
21.7” x 13.8” x 12.6”
gr.
32000
1,129.1
* The highest number of nozzles has been calculated by using a nozzle with flow rate 15 (0,042 l/min-0.012 USGpm) at 60 bar-850 psi.
Perfect
Vento Eco
with timer integrated
Description
Kit vento
Eco 202
Kit vento
Eco 402
F
OG
ECO
05
0,5 l/min,
60 bar, 200 W,
230 V-50 Hz
F
OG
ECO
1
0,9 l/min,
60 bar, 200 W,
230 V-50 Hz
M
ISTING
FAN
SWINGING
ø46 cm-18”
230 V-50 Hz,
125 Watt
M
ISTING
RING
made of
stainless steel
for 6 nozzlesi
H.
P
.
POLYAMIDE
PIPE
ø6,35 mm-1/4”,
(metres)
R
UBBERIZED
SS
CLAMP
to x polyamide pipe
ø6,35 mm-1/4”
C
AP
NOZZLE
HOLE
made of
nickeled brass
T
EE
QUICK
FITTING
made of
nickeled brass
N
ICKELED
BRASS
NOZZLE
0,15 with
anti-drip check valve
thread 10/24UNC/2A
Anti-drip
system
Perfect
Electronic
Techncial data
Fog Eco module
•
Frame
made of galvanized plate with
plastic cover.
•
Motor-pump
, 1420 Rpm, 230 V-50 Hz
with axial pump 2 plungers
•
Unloader valve
.
•
Thermal protection
against current surge
•
Integrated digital timer,
sets the duty cycle,
manual and automatic working, 24 hours
scheduling.
•
L.p. pressure switch
for lack of water
•
Anti-drip Electronic System
, inlet water
•
Cleanable water filter
Technical features
Optional and components
Subjects
Page
•
Misting fan
76
•
Optional - remote control
79
•
Polyamide pipe line ø9,6 mm-3/8”
114
•
Grilamid pipe line ø9,6 mm-3/8”
115
•
Polyamide pipe line ø12,7 mm-1/2”
116
•
Nickeled brass fitings ø9,6 mm-3/8”
114
•
Stainless fittings ø9,6 mm-3/8”
115
•
Nickeled brass fittings ø12,7 mm-1/2”
116
•
Optional - solenoid valves
122
•
Fog nozzles
128
•
Fog nozzles accessories
129
• Packaging size:
a
85 cm
b
60 cm
c
95 cm
Perfect VENTO kits
are supplied completely with all accessories
required for installation.
Our fog modules are made with selected
components speci cally designed
for fogging systems, featuring extremely
sophisticated and innovative systems.
