Idrobase katalog - page 39

67
ZX.0567
FOG PRO 1
ZX.0550
FOG PRO 2
ZX.0551
FOG PRO 4
a
b
c
PC.KV602 PC.KV604 PC.KV606
1
1
1
2
4
6
2
4
6
25
50
75
20
40
65
1
3
5
12
24
36
Optional and components
Frame
made of galvanized plate with
stainless steel cover.
Motor-pump
, 1450 Rpm, 230 V-50 Hz
with axial pump, 3 plungers with terminal
part in ceramic and brass head.
Unloader valve
.
L.p. solenoid valve
230 V-50 Hz,
inlet water.
H.p. solenoid valve
230 V-50 Hz,
to unload the h.p. line.
(It is active only in the presence of a
remote control connected).
L.p. pressure switch
for lack of water
Electric board
complete with:
ON/OFF thermal switch, remote control
switch and timer to relay h.p. solenoid
valve. It is ready to be connected to an
external device.
Cooling fan
Technical features
• Packaging size:
a
85 cm
b
60 cm
c
85 cm
Code
Model
* No.
nozzles
Pressure Flow rate
Power absorbed
Dimensions
W x L x H
Weight
25
60 bar
850 psi
1 l/min
0.26 USGpm
700 W (1x230 V-50 Hz)
60 x 30 x 30 cm
23.6” x 11.8” x 11.8”
gr.
oz.
29500
1,042.0
50
60 bar
850 psi
2 l/min
0.52 USGpm
720 W (1x230 V-50 Hz)
60 x 30 x 30 cm
23.6” x 11.8” x 11.8”
gr.
oz.
29500
1,042.0
95
60 bar
850 psi
4 l/min
1.05 USGpm
950 W (1x230 V-50 Hz)
60 x 30 x 30 cm
23.6” x 11.8” x 11.8”
gr.
oz.
29500
1,042.0
* The highest number of nozzles has been calculated by using a nozzle with flow rate 15 (0,042 l/min-0.012 USGpm) at 60 bar-850 psi.
Perfect VENTO kits
are completely supplied with all accessories
required for installation.
Our fog modules are made with selected
components speci cally designed
for fogging systems, featuring extremely
sophisticated and innovative systems.
Perfect
Vento Pro
Description
Kit Vento
Pro 602
Kit Vento
Pro 604
Kit Vento
Pro 606
F
OG
PRO
1
,
1 l/min,
60 bar, 700 W,
230 V-50 Hz
F
OG
PRO
2
,
2 l/min,
60 bar, 720 W,
230 V-50 Hz
M
ISTING
FAN
SWINGING
ø46 cm-18”
230 V-50 Hz,
125 Watt
M
ISTING
RING
made of
stainless steel
for 6 nozzlesi
H.
P
.
POLYAMIDE
PIPE
ø6,35 mm-1/4”,
(metres)
R
UBBERIZED
SS
CLAMP
to x polyamide pipe
ø6,35 mm-1/4”
T
EE
QUICK
FITTING
made of
nickeled brass
N
ICKELED
BRASS
NOZZLE
0,15 with
anti-drip check valve
thread 10/24UNC/2A
Anti-drip
system
Perfect
Electronic
Technical data
Fog Pro module
Subjects
Page
Misting fan
76
Optional - remote control
79
Polyamide pipe line ø9,6 mm-3/8”
114
Grilamid pipe line ø9,6 mm-3/8”
115
Polyamide pipe line ø12,7 mm-1/2”
116
Nickeled brass fitings ø9,6 mm-3/8”
114
Stainless fittings ø9,6 mm-3/8”
115
Nickeled brass fittings ø12,7 mm-1/2”
116
Optional - solenoid valves
122
Fog nozzles
128
Fog nozzles accessories
129
