ZX.5022
ZX.5023
Technical features:
Fog 30S
is composed by:
• Brass blade pump.
• Electric motor IP54, 230V, 50Hz.
• Pressure switch for lack of water.
• Water filter mignon with 5 mcrs cartridge.
• Electric board with timer to set duty cycle and Fan 360° ON/OFF
switch.
• 25 lt tank
(it allows 4 hours autonomy with duty cycle function)
.
• Box for fog module made of acacia wood.
Technical features:
Fan 360°
is made of painted steel and equipped with:
• Electric motor 1375 G/min a 230 V-50 Hz,
power absorbed 96 Watt a 0,47 A,
• Fan with ON/OFF switch,
• Noise 59 dB,
• Air flow 4000 m
3
/h,
• Flow range 3-4 m
• 6-hole ring (thread 10/24UNC/A) and 6 nozzles with hole
0,20 mm.
Tavolino
360°
version h750
Complete with:
• White table made of acacia wood with non-toxic UV resi-
stant painting (dimensions: ø1100 mm, H 750 mm). • Fan
360° complete with mist ring and 6 fog nozzles 0,20mm.
• Module Fog 30 S
(code ZX.8061, 25 lts tank, operating
time: 4 hours with duty-cycle function)
• Connecting line
Kit.
OPTIONAL
• White chair made of acacia wood with non-toxic UV re-
sistant painting.
Tavolino
360°
version h1000
Complete with:
• White table made of acacia wood with non-toxic UV resi-
stant painting (dimensions: ø1100 mm, H 1000 mm). • Fan
360° complete with mist ring and 6 fog nozzles 0,20mm.
• Module Fog 30 S
(code ZX.8061, 25 lts tank, operating
time: 4 hours with duty-cycle function)
• Connecting line
Kit.
OPTIONAL
• White chair made of acacia wood with non-toxic UV re-
sistant painting.
