ZX.KLC360
ZX.5036-S
ZX.5036-P
FOG 30-8
8
300 W (230 V-50 Hz)
FOG 30-14
14
300 W (230 V-50 Hz)
FOG 30-20
20
300 W (230 V-50 Hz)
ZX.8062
ZX.8060
ZX.8063
FOG 30S-8
8
300 W (230 V-50 Hz)
FOG 30S-14
14
300 W (230 V-50 Hz)
FOG 30S-20
20
300 W (230 V-50 Hz)
ZX.8064
ZX.8061
ZX.8065
Code
Model
No. of nozzles Pressure
Flow rate
Power absorbed
30 bar
0,5 l/min
30 bar
0,8 l/min
30 bar
1,10 l/min
Fog 30
is designed to feed 360° cooling systems and it is complete with:
• Stainless steel frame and base made of zinc-coated sheet. • Brass blade pump. • Electric motor IP54,
230V, 50Hz. • Pressure switch for lack of water. • Water filter with 5-micron cartridge. • Electric board with
timer to set duty cycle, and Fan 360° ON/OFF switch.
Code
Model
No. of nozzles Pressure
Flow rate
Power absorbed
30 bar
0,5 l/min
30 bar
0,8 l/min
30 bar
1,10 l/min
Fog 30S
is designed to feed 360° cooling systems and it is complete with:
• Brass blade pump. • Electric motor IP54, 230V, 50Hz. • Pressure switch for lack of water. • Water
filter with 5-micron cartridge. • Electric board with timer to set duty cycle, and Fan 360° ON/OFF
switch. • 25 lts tank. • Acacia wood box
for fog
module and tank.
Fan 360°
is an extraordinary new product in the fog sector,
its radial
diffusion at 360° allows six-times-bigger coverage
than traditional online systems, increasing the effectiveness
of sprinkler systems.
Perfect for both cooling and humidification indoors or in se-
mi-open area.
Fan
360°
pedestal
version
•
Fan 360° pedestal
version
, complete with
6-hole ring threaded
10/24UNC/A, 6 nickeled
brass nozzles 0,20 mm
hole, base support and
2-piece stick (Dimen-
sions: 270 cm height).
96 W, 230 V-50 Hz.
Fan
360°
hanging
version
•
Fan 360° hanging version
, complete with
6-hole ring threaded 10/24UNC/A, 6 nickeled
brass nozzles 0,20 mm hole and rod support
to fix the fan on the ceiling. 96 W, 230 V-50 Hz.
Kit
LINEA
collegamento
The Connecting Line Kit
includes all the necessary articles for the electrical and water
connections between the 360° cooling devices and the Fog module.
ppp
F
F
p
F
K
c
