DF 583 N
1,75 m
STANDARD
BÛCHES
50
cm
2
2+1
Orféo
90
Technical characteristics: see page 114
Double-sided view of the fire
for installation in the centre
of a room
Output 71 %
Nominal output 10 kW
Two glass sides
Cast iron lining
Side opening on both sides
Lift-up door on one side
Large ashpan 4,8 l.
Warm air distributor fitted
as standard (natural
convection only)
"Clean glass" system
2 warm air nozzles
ø
150 mm included
Optional:
• ORFEO decorative front
Strong
points
DF 583 N
1 Lift-up door
1 side-opening door
(*) Side opening for easy cleaning of the glass.
Adaptable to
the ORFEO
range of deco-
rative fronts
See page 10
"Flamme Verte" quality charter
Clean glass system
For 50 cm logs*
Heating body with cast iron lining
Air distributor included
Triple envelope heating body (2 + 1):
airtight combustion chamber + interior lining
+ third envelope for greater safety
Levelling screws, for secure,
stable installation
Flue valve:
reduces wood consumption
Surface heated (table p. 113)
Support foot included
Lift-up door
Smoke flue with collector:
allows any condensate to be
burned completely
1 side
MODEL
DF 583 N
DOOR OPENING
LIFT-UP*
REF.
111868
* Indication of the standard size of logs on general sale.
1450 - 1620
180-350
982
465
80
760
780
690
34
525
490
545
Ø146
Ø200
545
760
Ø200
