ZX.6000
ZX.6001
ZX.6002
2000 mm
2730 mm
Ø 70 mm
Ø 300 mm
2000 mm
Ø 70 mm
Ø 12 mm
3500 mm
Ø 300 mm
Ø 35 mm
2800 mm
Ø 890 mm
Cooling accessories
All of our cooling accessories are made from
AISI 304 STAINLESS STEEL
. The installation is
simple and quick to perform and does not require the use of any specialist equipment.
The connections for the pipes are made from AISI 304 stainless steel and are equipped with
compression ttings with “slip-lock” connections to t the high pressure polyamide pipe
(max 60 bar-
850 psi
) ø9,5x5 mm-3/8”. They have to be connected to the fog module.
Technical features of the cooling accessories:
Optional and components
gr. 22000
oz. 776.0
Palma Rinfrescante
Technical
features:
• Working pressure:
60 bar-
850 psi
• Water supply at 60 bar:
1,00 l/min-
0.26 USGpm
• Stainless steel AISI 304,
hole 0,15 mm with
anti-drip check valve:
no. 24
gr. 11000
oz. 388.0
Parasole Rinfrescante
Technical
features:
• Working pressure:
60 bar-
850 psi
• Water supply at 60 bar:
0,50 l/min-
0.13 USGpm
• Stainless steel AISI 304,
hole 0,15 mm with
anti-drip check valve:
no. 12
gr. 14000
oz. 494.0
Stelo Rinfrescante
Technical
features:
• Working pressure:
60 bar-
850 psi
• Water supply at 60 bar:
0,43 l/min-
0.11 USGpm
• Stainless steel AISI 304,
hole 0,15 mm with
anti-drip check valve:
no. 10
Subject
Page
•
Fog module Eco
64
•
Fog moduel Pro
67
•
Optiona - inlet water filter
126
•
Fog nozzles and accessories
128
