Duty cycle + humidistat remote control - PERFECT UMI PRO
This remote control for fogging systems, controls and keeps the degree
of humidity in a closed area (humidistat), with the possibility to adjust the
progressive intake of humidity (timer pause / work).
The double advantage is higher precision in reaching the desire parameter
and avoiding excessive levels
of humidity
which can be caused
when the probe takes too long
in responding.
It works only through a
humidity probe with
4-20 mA current output
signal, the differential rate
is adjustable
from 0,5% to 10%
of relative humidity.
Easy to program even
by untrained people.
gr. 2200 /
oz. 77.0
Duty cycle remote control - PERFECT TIME
This remote control for fogging systems needs 230V-50Hz.
It enables you to set the ON-OFF of the operating time which is shown
on the display.
Easy to program even by unqualified people. It can be used also
manual remote control.
gr. 1200 /
oz. 42.0
Humidistat remote control - PERFECT UMI
The remote control for fogging systems PERFECT
COOL is ideal to control and keep the degree of
humidity you wish in a closed area.
It works only through a humidity probe with a
4-20mA current output signal,
the differential rate
is adjustable
from 0,5% to 10%
of relative humidity.
Easy to program
even by untrained
people.
gr. 100 /
oz. 3.6
Humidity probe - PERFECT PROBE
The PERFECT PROBE humidity sensor is ideal to
apply PERFECT COOL and PERFECT COOL PRO
measuring device.
Output current signal is 4-20mA.
Technical features:
• Range measure humidity:
15 - 90% rh
• Precision:
± 5%
• Survey time:
60 sec
constant conditions
• Protection rating:
IP54
gr. 170 /
oz. 6.0
Humidity probe - PERFECT PROBE PRO
The PERFECT PROBE PRO humidity sensor is
ideal to apply PERFECT COOL
and PERFECT COOL PRO measuring device.
Output current signal is 4-20mA.
Technical features:
• Range measure humidity:
0 - 100% rh
• Precision:
± 2%
• Survey time:
30 sec
constant conditions
• Protection rating:
IP65
gr. 1370 /
oz. 48.4
Water sterilizer UV 300
complete with connections to connect
60 bar fog module.
Technical features:
• Stainless steel cover
500x63 mm -
19.70”x2.5”
• Max flow rate
8 l/min -
2.10 USGpm
• Max pressure
6 bar -
85 psi
• Power supply
230 V-50/60 Hz
• Power absorbed
15 W
• Connection
inlet and outlet 1/2 M
Optional
gr. 1200 /
oz. 42.0
Thermostat remote control
This remote control for fogging systems,
enables you to program the
ON / OFF temperature
of FOG systems.
It includes a survey
probe of temperature.
