Diadème
Diadème 501 B-N
K
2
2+1
STANDARD
BÛCHES
50
cm
BY PASS
BY PASS
INTERIEUR
BRIQUE
80
Technical characteristics: see page 114
The beauty of the fire, all in curves
Output: 70% (Premium), 73% (Pack)
Nominal output 11 kW (Premium) or 13 kW (Pack)
Cast iron (501) or brick (531) lining
Lift-up door
Safety locking
Side opening to facilitate cleaning of the glass
"Clean glass" system
Combustion air and valve control levers
Options :
• KTE 152 biturbo kit
• KT 1455 turbine kit
• KRT 260 A adapter (only with KT 1455)
• Warm air nozzles
ø
150 mm
• Warm air distributor cover
CDA 450 A (on Premium)
Strong
points
PREMIUM
PACK VERSION ADVANTAGES
Inoxis THR heat exchanger unit:
helps concentrate the heat and
amplifies the clean glass system
Post-combustion:
the smoke is burnt a second time
for better output
Pre-heating of the secondary air
in a special heat exchanger
IN’AIR connection module,
for operation independently of the
mechanical ventilation system
Air distributor included
Bypass valve:
new generation valve
for better output
Surface heated (table p. 113)
* Indication of the standard size of logs on general sale.
Heating body with cast iron lining
Optional air distributor
Flue valve:
reduces wood consumption
Lift-up door
"Flamme Verte" quality charter
Clean glass system
For 50 cm logs*
Triple envelope heating body (2 + 1):
airtight combustion chamber + interior lining
+ third envelope for greater safety
Brick interior
Diadème 531
Diadème 501
Automatic locking glass door
Support foot included
Smoke collector with Inoxis HR smoke
baffle: helps concentrate the heat and
amplifies the clean glass system
Smoke flue with collector:
allows any condensate to be
burned completely
2-point side door locking:
gives a better seal
Levelling screws, for secure,
stable installation
Anti-smoke compartment: recovers
the smoke that billows out when
the door is opened too quickly
Optional turbines
Surface heated (table p. 113)
NEW
