Univers
UNIVERS 2-200
AD-PN
UNIVERS 2-201
A-PACK PN
2
2+1
STANDARD
BÛCHES
50
cm
BY PASS
BY PASS
INTERIEUR
BRIQUE
82
Technical characteristics: see page 115
Fully enjoy the sight of the fire
Output: 71% (Premium), 72% (Pack)
Nominal output 11 kW (Premium)
or 13 kW (Pack)
Highly user friendly
Optimised glass surface 71 x 51 cm
Lift-up door for Univers 201-231
and side opening for easy
to facilitate cleaning of glass
Side opening for Univers 200-230
Large ashpan 4.8 l.
"Clean glass" system
Options (all models except
ventilated Pack):
• KTE 152 biturbo kit
• KT 1455 turbine
• KRT 260 A adapter
(only with KT 1455)
Options (all models):
• Warm air nozzles
ø
150 mm
• ORFEO decorative front
• Warm air distributor cover
CDA 200 A (on Premium)
Strong
points
Univers 200-201
French standard
Clean glass system
For 50 cm logs*
Triple envelope heating body (2 + 1):
airtight combustion chamber + interior lining
+ third envelope for greater safety
Heating body with cast iron lining
Optional air distributor
Flue valve:
reduces wood consumption
Brick interior
Univers 230-231
"Flamme Verte" quality charter
PREMIUM
Smoke collector with Inoxis HR smoke baffle:
helps concentrate the heat and improves the
performance clean glass system
Smoke flue with collector:
allows any condensate to be
burned completely
2-point side door locking:
gives a better seal
Levelling screws, for secure,
stable installation
Support foot included
Anti-smoke compartment: recovers
the smoke that billows out when
the door is opened too quickly
Optional turbines
Surface heated (table p. 113)
Lift-up door
Univers
201 -231
Inoxis THR heat exchanger unit:
helps concentrate the heat and
amplifies the clean glass system
Post-combustion:
the smoke is burnt a second time
for better output
Pre-heating of the secondary air
in a special heat exchanger
IN’AIR connection module,
for operation independently of the
mechanical ventilation system
Air distributor included
Bypass valve:
new generation valve
for better output
Surface heated (table p. 113)
PACK VERSION ADVANTAGES
* Indication of the standard size of logs on general sale.
