Émeraude
ÉMERAUDE 1801
1,75 m
1800
1801
1821
1831
STANDARD
BÛCHES
50
cm
K
INTERIEUR
BRIQUE
86
Technical characteristics: see page 114
Panoramic view of the fire
Output 74 %
Nominal output
11 kW / 10 kW (1800 D)
Cast iron or brick interior
Cast iron plates removable
from the inside of the firebox
Double-sided heating body
(resists thermal shocks and
provides total airtightness)
Double safety locking
Side opening (1800, 1800 D)
or lift-up opening
(1801, 1821, 1831)
Flue valve
Curved glass door
"Clean glass" system
Options :
• KTE 152 biturbo kit
• DA 1800
• 2 extra hot air nozzles
ø
150 mm
Strong
points
ÉMERAUDE 1800 D
ÉMERAUDE 1801 / 1821 / 1831
"Flamme Verte" quality charter
Clean glass system
For 50 cm logs*
Levelling screws, for secure,
stable installation
Optional turbines
Surface heated (table p. 113)
Support foot included
Except 1800
Except 1800
Lift-up door
Smoke collector with Inoxis HR smoke
baffle: helps concentrate the heat and
amplifies the clean glass system
Automatic locking glas door
Flue valve:
reduces wood consumption
Heating body with cast iron lining
Optional air distributor
1800-1801-1821
Brick interior
1831
MODEL
ÉMERAUDE 1800 ÉMERAUDE 1801 / 1821 / 1831
VIEW
CURVED
CURVED
DOOR OPENING
SIDE
REF.
LIFT-UP*
REF.
1800 / 1800 D 111357
1801
111358
1821
111370
1831
111372
(*) Side opening for easy cleaning of the glass.
* Indication of the standard size of logs on general sale.
R=500
682
460
R=500
682
460
576
512
