CARAT 58
1,75 m
STANDARD
BÛCHES
50
cm
CARAT 58
2
2+1
88
Technical characteristics: see page 114
Square view of the fire
Output 78 %
Nominal output 9 kW
"Triple envelope" combustion chamber
Cast iron interior
IN’AIR combustion module
Lift-up opening
Hot air distribution system included
Flue valve
Glass door tilts for cleaning
Large easily removable ashpan
"Clean glass" system »
Strong
points
1682/1717
518
737
165
511
180
653
1127
331/366
1375/1410
567
557
512
342
514
668
CARAT 58
is also available in
a connectable version
CARAT 58 R
.
MODEL
CARAT 58
CARAT 58 R
DOOR OPENING
LIFT-UP*
REF.
111931
REF.
111932
DIMENSIONS W
X
H
X
D
74
X
168
TO
172
X
56
(*) Side opening for easy cleaning of the glass.
* Indication of the standard size of logs on general sale.
Flue valve:
reduces wood consumption
"Flamme Verte" quality charter
Clean glass system
For 50 cm logs*
Triple envelope heating body (2 + 1):
airtight combustion chamber + interior lining
+ third envelope for greater safety
Air distributor included
Cast iron interior
Levelling screws, for secure,
stable installation
Support foot included
Lift-up door
Smoke collector with Inoxis HR smoke
baffle: helps concentrate the heat and
amplifies the clean glass system
Optional turbines
Surface heated (table p. 113)
Pre-heating of the secondary air
in a special heat exchanger
IN’AIR connection module,
for operation independently of the
mechanical ventilation system
