Cosmos / Diamant
1,75 m
COSMOS
1520 ADN
DIAMANT
1421 AN
Cosmos
Diamant
2
2+1
STANDARD
BÛCHES
50
cm
Diamant
84
Technical characteristics: see page 114
COSMOS 1520 ADN
Curved front
Output 71 %
Nominal output 8 kW
"Triple envelope"
heating body
IN’AIR combustion
module
Cast iron door and inside;
side opening
Flue valve
Large ashpan 3,9 l.
Warm air distributor
included
"Clean glass" system
INOXIS HR smoke baffle»
Optional:
• KTE 152 biturbo kit
DIAMANT 1421 AN
Prismatic view of the fire
Output 71 %
Nominal output 9 kW
"Triple envelope"
heating body
IN’AIR combustion
module
Cast iron interior
Lift-up and side opening
to facilitate cleaning of
the glass
Flue valve
Large ashpan 3,9 l.
"Clean glass" system »
Warm air distributor
included»
Optional:
• KTE 152 biturbo kit
(*) Side opening for easy cleaning of the glass.
"Flamme Verte" quality charter
Clean glass system
For 50 cm logs*
Triple envelope heating body (2 + 1):
airtight combustion chamber + interior lining
+ third envelope for greater safety
Heating body with cast iron lining
Levelling screws, for secure,
stable installation
Air distributor included
Flue valve:
reduces wood consumption
Optional turbines
Surface heated (table p. 113)
Support foot included
IN’AIR connection module,
for operation independently of the
mechanical ventilation system
Lift-up door
COSMOS
1520 ADN
DIAMANT 1421 AN
MODEL
COSMOS 1520 ADN DIAMANT 1421 AN
VIEW
CURVED
PRISMATIC
DOOR OPENING
SIDE REF.
111828
LIFT-UP
REF.
111826
* Indication of the standard size of logs on general sale.
