FV 40 D / FV 51
FV 51
FV 40 D
INTERIEUR
BRIQUE
2
2+1
33
cm
STANDARD
BÛCHES
85
Technical characteristics: see page 115
FV 40 D
Vertical view of the fire
Output 75 %
Nominal output 8 kW
"Triple envelope"
combustion chamber
INOXIS THR
smoke baffle
Side opening
Large easily
removable ashpan
Logs 40 cm (horizontally)
or 50 cm max. (vertically)
Optional warm air
distributor
FV 51
Vertical view of the fire
Output 71 %
Nominal output 9 kW
"Triple envelope"
combustion chamber
IN’AIR combustion
module
INOXIS HR
smoke baffle
Glass door lifts up and
tilts for cleaning
Large easily
removable ashpan
Logs 40 cm (horizontally)
or 50 cm max. (vertically)
Warm air distributor
included
442
420
408
1084-1120
1687-1723
180
552
640
625
441
1090-1130
470
Ø150
42
147
536
700
640
112
112
401
200
266-308
Ø125
Ø150
FV 51
FV 40 D
(*) Side opening for easy cleaning of the glass.
"Flamme Verte" quality charter
Clean glass system
For 33 cm logs*
Triple envelope heating body (2 + 1):
airtight combustion chamber + interior lining
+ third envelope for greater safety
Brick interior
Air distributor included
( optionalontheFV40)
Flue valve:
reduces wood consumption
Lift-up door
FV 51
Support foot included
Pre-heating of the secondary air
in a special heat exchanger
IN’AIR connection module,
for operation independently of the
mechanical ventilation system
Levelling screws, for secure,
stable installation
Optional turbines
Surface heated (table p. 113)
Inoxis THR heat exchanger unit:
amplifies the concentration of the heat
and allows double combustion
FV 51
FV 40
FV 51
FV 51
FV 51
Smoke collector with Inoxis HR smoke
baffle: helps concentrate the heat and
amplifies the clean glass system
MODEL
FV 40 D
FV 51
DOOR OPENING
SIDE REF.
111475
LIFT-UP*
REF.
111871
DIMENSIONS W
X
H
X
D
62
X
109
TO
113
X
47
62
X
169
TO
172
X
55
* Indication of the standard size of logs on general sale.
